制冷系統標準測試工況--空調

發布時間：2021-10-07 人氣：1255

各地區的標準測試工況--空調

適用地區

名義制冷(℃)

最大制冷(℃)

最小制冷(℃)

凍結試驗(℃)

名義制熱(℃)

最大制熱(℃)

凝露/凝排(℃)

自動除霜(℃)

室內

室外

室內

室外

室內

室外

室內

室外

室內

室外

室內

室外

室內

室外

室內

室外

歐洲

----

中東

----

北美

26.7

19.4

35.0

23.9

32.2

22.8

43.3

25.6

21.1

15.6

2.1

15.6

21.1

----

8.3

6.1

26.7

----

23.9

18.3

26.7

23.9

26.7

23.9

南美

----

澳洲

----

東南亞

菲律賓

----

印度

----

15.5

其他地區

----

國內

----

參考標準：

1. ANSI/AHAM RAC-1-1992 （American National Standard Room Air Conditioners）

2. ISO 5151:1994(E) (Non-ducted Air –Conditioners and Heat Pumps-Testing and Rating)

3. SSA 385/1983 (METHODS OF TESTING ROOM AIR CONDITIONERS)

4. AS 1861.1-1988 （Air-conditioning units—Methods of assessing and rating performance Part 1）

5. IS 1391(Part 2) (SPLIT AIR CONDITIONERS)

6. PNS 240:1989 (Method of Testing and Rating Room Air Conditioners)

7. GB/T 7725-1996 房間空氣調節器

各地區的能效要求--空調

一、美國----窗式空調器

Without reverse cycle, with louvered sides

Rated Capacity

Less than 6000 Btu/h

6000 to 7999 Btu/h

8000 to 13999 Btu/h

14000 to 19999 Btu/h

20000 Btu/h or more

EER（Btu/Wh）

9.7

9.8

9.7

8.5

二、香港

For Widow Type

Energy Efficiency Grade	Grade 1	Grade 2	Grade3	Grade 4	Grade 5
EER （W/W）	≥2.66	2.66>EER≥2.38	2.38>EER≥ 2.15	2.15>EER≥1.89	EER<1.89

For Split Type

Energy Efficiency Grade	Grade 1	Grade 2	Grade3	Grade 4	Grade 5
EER （W/W）	≥3.04	3.04>EER≥2.72	2.72>EER≥2.46	2.46>EER≥2.15	EER<2.15

三、印度

For Split Type

Rated Capacity (kcal/h)	3000	4500	6000	7500	9000
Max Power Consumption (kw)	1.7	2.6	3.4	4.5	5.4

四、菲律賓

Rated Capacity (kJ/h)

Below 12000 kJ/h(3333W)

Above 12000 kJ/h

EER (kJ/Wh)

9.1(2.53W/W)

8.6(2.39)

五、澳洲

Single Phase Power

Star rating	1.0	1.5	2.0	2.5	3.0	3.5	4.0	4.5	5.0	5.5	6.0
EER of Cooling (W/W) (average of three units)	EER <2.15	2.3> EER≥2.15	2.45> EER≥2.3	2.6> EER≥2.45	2.75> EER≥2.6	2.9> EER≥2.75	3.05> EER≥2.9	3.2> EER≥3.05	3.35> EER≥3.2	3.5> EER≥3.35	EER≥3.5
COP of Heating (W/W) (average of three units)	EER <2.45	2.6> EER≥2.45	2.75> EER≥2.6	2.9> EER≥2.75	3.05> EER≥2.9	3.2> EER≥3.05	3.35> EER≥3.2	3.5> EER≥3.35	3.65> EER≥3.5	3.8> EER≥3.65	EER≥3.8

Three Phase Power

Rated Capacity (kW)	<10.0	10.0-12.5	12.6-15.5	15.6-18.0	18.1-25.0	25.1-30.0	30.1-37.5	37.6-45.5	45.6-65.0
EER of Cooling (W/W)	EER≥2.25	EER≥2.30	EER≥2.35	EER≥2.40	EER≥2.45	EER≥2.50	EER≥2.55	EER≥2.60	EER≥2.65

六．歐洲

Table 1 – Air-cooled air-conditioners

Table 1.1

Energy efficiency class	Spilt and multi-spilt appliance
A	3.20< EER
B	3.20≥ EER >3.00
C	3.00≥ EER >2.80
D	2.80≥ EER >2.60
E	2.60≥ EER >2.40
F	2.40≥ EER >2.20
G	2.20≥ EER

Table 1.2

Energy efficiency class	Packaged(1)
A	3.00< EER
B	3.00≥ EER >2.80
C	2.80≥ EER >2.60
D	2.60≥ EER >2.40
E	2.40≥ EER >2.20
F	2.20≥ EER >2.00
G	2.00≥ EER

Packaged ‘double ducts’ units ( known commercially as ‘double ducts’ )defined as ‘ air conditioner completely positioned inside the conditioned space, with the condenser air intake and air discharge connected to the outside by mean of two ducts’, will be classified according to table 1.2 with a correction factor of – 0.4.

Table 1.3

Energy efficiency class	Single-duct
A	2.60< EER
B	2.60≥ EER >2.40
C	2.40≥ EER >2.20
D	2.20≥ EER >2.00
E	2.00≥ EER >1.80
F	1.80≥ EER >1.60
G	1.60≥ EER

2. The heating mode

Table 2 air-cooled air-conditioners- heating mode

TABLE 2.1

Energy efficiency class	Spilt and multi-spilt appliance
A	3.60
B	3.60≥ COP >3.40
C	3.40≥ COP >2.20
D	3.20≥ EER >2.80
E	2.80≥ EER >2.60
F	2.60≥ EER >2.40
G	2.40≥ EER
